- Nominal Voltage: 46.8V/48.1V
- Nominal Capacity: 15Ah/721.5Wh
- Voltage Range: 36.4V-54.6V
- Max. Continuous Discharge Current: 10A
- Max. Discharge Peak Current: 15A
- Communication Protocol: /
- Dimension: 162 x 75 x 60 mm
- Weight: 3500g ± 200g
-
P/N: LP13S3P8A10AL001
-
P/N: LP4S1P50A100AF005
- Nominal Voltage: 12.8V
- Nominal Capacity: 100Ah/1280Wh
- Voltage Range: 10.0V~14.6V
- Max. Continuous Discharge Current: 100A
- Max. Discharge Peak Current: 200A
- Communication Protocol: /
- Dimension: 300 x 250 x 145 mm
- Weight: 12.7kg ± 0.5kg
-
P/N: LP4S1P50A100AF002
- Nominal Voltage: 12.8V
- Nominal Capacity: 100Ah/1280Wh
- Voltage Range: 10.0V~14.6V
- Max. Continuous Discharge Current: 100A
- Max. Discharge Peak Current: 200A
- Communication Protocol: /
- Dimension: 270 x 165 x 145 mm
- Weight: 11.3kg ± 0.5kg
-
P/N: LPESS48200F001
- Nominal Voltage: 51.2V
- Nominal Capacity: 200Ah /10240Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 150A
- Max. Discharge Peak Current: 160A
- Communication Protocol: Optional(CANBus/MODBus- RS485/232/UART/Bluetooth)
- Dimension: 600 x260 x 720 mm
- Weight: 98kg ± 3kg
-
P/N: Far East 21700 6000mAh cell 60A
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 6000mAh
- Max. Charge Current: 4.2A
- Max. Discharge Current: 6.0A
- Cell Weight: 75g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 21700 5500mAh cell 55A
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 5500mAh
- Max. Charge Current: 2.75A
- Max. Discharge Current: 5.5A
- Cell Weight: 73g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 21700 5000mAh cell 50M
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 5000mAh
- Max. Charge Current: 5A
- Max. Discharge Current: 30A
- Cell Weight: 73g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 21700 4000mAh cell 40M
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 4000mAh
- Max. Charge Current: 6A
- Max. Discharge Current: 45A
- Cell Weight: 71g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 16850 4000mAh cell 40EA
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 4000mAh
- Max. Charge Current: 4.0A
- Max. Discharge Current: 8.0A
- Cell Weight: 50g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 16850 3800mAh cell 38EA
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 3800mAh
- Max. Charge Current: 3.8A
- Max. Discharge Current: 7.6A
- Cell Weight: 48g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 16850 3500mAh cell 35EA
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 3500mAh
- Max. Charge Current: 3.5A
- Max. Discharge Current: 7.0A
- Cell Weight: 48g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 16850 3300mAh cell 33EA
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 3300mAh
- Max. Charge Current: 3.3A
- Max. Discharge Current: 6.6A
- Cell Weight: 48g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 16850 2900mAh cell 29EA
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.75V
- Capacity: 2900mAh
- Max. Charge Current: 2.9A
- Max. Discharge Current: 5.8A
- Cell Weight: 47g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 16850 2600mAh cell 26EBX
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.75V
- Capacity: 2600mAh
- Max. Charge Current: 2.6A
- Max. Discharge Current: 5.2A
- Cell Weight: 48g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 16850 3000mAh cell 30M
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 3000mAh
- Max. Charge Current: 4A
- Max. Discharge Current: 30A
- Cell Weight: 46.5g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 16850 2500mAh cell 25M
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 2500mAh
- Max. Charge Current: 4A
- Max. Discharge Current: 30A
- Cell Weight: 46.5g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: Far East 16850 2000mAh cell 20HL
- Nominal Voltage: 3.6V
- Charging Voltage: 4.2V
- Discharge Cut-off Voltage: 2.5V
- Capacity: 2000mAh
- Max. Charge Current: 4A
- Max. Discharge Current: 30A
- Cell Weight: 46.5g
- Charge Operating Temperature: 0 - 45°C
- Discharge Operating Temperature: -20 - 60°C
-
P/N: LP8S4P20A20AF001
- Nominal Voltage: 24V/25.6V
- Nominal Capacity: 60Ah/1536Wh
- Voltage Range: 20V~29.2V
- Max. Continuous Discharge Current: 20A
- Max. Discharge Peak Current: 30A
- Communication Protocol: /
- Dimension: 600 x 115 x 115 mm
- Weight: 9800g ± 50g
-
P/N: LP8S3P20A20AF001
- Nominal Voltage: 24V/25.6V
- Nominal Capacity: 45Ah/1152Wh
- Voltage Range: 20V~29.2V
- Max. Continuous Discharge Current: 20A
- Max. Discharge Peak Current: 30A
- Communication Protocol: /
- Dimension: 600 x 115 x 75 mm
- Weight: 7200g ± 50g
-
P/N: LP18S1P5A12AF002
- Nominal Voltage: 57.6V
- Nominal Capacity: 6Ah/345.6Wh
- Voltage Range: 45V~65.7V
- Max. Continuous Discharge Current: 12A
- Max. Discharge Peak Current: 18A
- Communication Protocol: RS485
- Dimension: 325 x 65 x 85 mm
- Weight: 3.7kg ± 100g
-
P/N: LP18S1P5A12AF001
- Nominal Voltage: 57.6V
- Nominal Capacity: 6Ah/345.6Wh
- Voltage Range: 45V~65.7V
- Max. Continuous Discharge Current: 12A
- Max. Discharge Peak Current: 18A
- Communication Protocol: /
- Dimension: 325 x 65 x 85 mm
- Weight: 3.62kg ± 50g
-
P/N: LP18S1P5A12AF001
- Nominal Voltage: 57.6V
- Nominal Capacity: 6Ah/345.6Wh
- Voltage Range: 45V~65.7V
- Max. Continuous Discharge Current: 12A
- Max. Discharge Peak Current: 18A
- Communication Protocol: /
- Dimension: 325 x 65 x 85 mm
- Weight: 3.62kg ± 50g
-
P/N: LP16S2P15A30AF001
- Nominal Voltage: 51.2V
- Nominal Capacity: 30Ah/1536Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 30A
- Max. Discharge Peak Current: 60A
- Communication Protocol: Uart
- Dimension: 330 x 165 x 170 mm
- Weight: 15Kg ± 0.5Kg
-
P/N: LP2S1P2A2AL010
- Nominal Voltage: 7.4V
- Nominal Capacity: 3.35Ah/24.79W
- Voltage Range: 5.60V~8.4V
- Max. Continuous Discharge Current: 2A
- Max. Discharge Peak Current: 3A
- Communication Protocol: /
- Dimension: 75 x 39 x 30 mm
- Weight: 190g ± 50g
