P/N: LRL2430
- Nominal Voltage: 24V
- Nominal Capacity: 30Ah /720Wh
- Voltage Range: 20V~29.2V
- Max. Continuous Discharge Current: 30A
- Max. Discharge Peak Current: 45A
- Communication Protocol: Optional(CANBus, MODBus- RS485/232, UART and bluetooth)
- Dimension: 257 x 200 x 132mm
- Weight: 5.0kg ± 0.2kg
-
P/N: LP4850B001
- Nominal Voltage: 51.2V
- Nominal Capacity: 50Ah/2,560Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 50A
- Max. Discharge Peak Current: 80A
- Communication Protocol: Modbus - RS485 & CANBus
- Dimension: 440 x 373 x 180 mm
- Weight: 35kg ± 1kg
-
P/N: LJQ-QDQ-001
- Input Voltage: 100~250V AC Single Phase
- Output Voltage: 100~250V AC Single Phase
- Max. Output Current: 16A
- Max. Output Power: 3.7KW
- Input frequency: 47~63Hz
- Plug material: ABS
- IP Rating: IP44
- Operating temperature: -30℃~+50℃
-
P/N: LP48100B001
- Nominal Voltage: 51.2V
- Nominal Capacity: 100Ah/5,120Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 100A
- Max. Discharge Peak Current: 130A
- Communication Protocol: Modbus - RS485 & CANBus
- Dimension: 470 x 442 x 180 mm
- Weight: 44kg ± 1kg
-
P/N: LP7S4P20A20AF001
- Nominal Voltage: 22.4V
- Nominal Capacity: 18Ah/403.2Wh
- Voltage Range: 17.50V~25.55V
- Max. Continuous Discharge Current: 20A
- Max. Discharge Peak Current: 50A
- Communication Protocol: /
- Dimension: 425 x 56 x 80 mm
- Weight: 3000g ± 30g
-
P/N: LP7S8P30A30AF01
- Nominal Voltage: 22.4V
- Nominal Capacity: 36Ah/806.4Wh
- Voltage Range: 17.50V~25.55V
- Max. Continuous Discharge Current: 30A
- Max. Discharge Peak Current: 150A
- Communication Protocol: /
- Dimension: 425 x 112 x 80 mm
- Weight: 5900g ± 30g
-
P/N: L P48280B001
- Nominal Voltage: 51.2V
- Nominal Capacity: 280Ah/14336Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 100A
- Max. Discharge Peak Current: 130A
- Communication Protocol: Modbus - RS485 & CANBus
- Dimension: 638 x 602 x 232 mm
- Weight: 120kg ± 1kg
-
P/N: LP4850B001
- Nominal Voltage: 51.2V
- Nominal Capacity: 50Ah/2,560Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 50A
- Max. Discharge Peak Current: 80A
- Communication Protocol: Modbus - RS485 & CANBus
- Dimension: 440 x 373 x 180 mm
- Weight: 35kg ± 1kg
-
P/N: LP4850B001
- Nominal Voltage: 51.2V
- Nominal Capacity: 50Ah/2,560Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 50A
- Max. Discharge Peak Current: 80A
- Communication Protocol: Modbus - RS485 & CANBus
- Dimension: 440 x 373 x 180 mm
- Weight: 35kg ± 1kg
-
P/N: LP4850B001
- Nominal Voltage: 51.2V
- Nominal Capacity: 50Ah/2,560Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 50A
- Max. Discharge Peak Current: 80A
- Communication Protocol: Modbus - RS485 & CANBus
- Dimension: 440 x 373 x 180 mm
- Weight: 35kg ± 1kg
-
P/N: LP48100B001
- Nominal Voltage: 51.2V
- Nominal Capacity: 100Ah/5,120Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 100A
- Max. Discharge Peak Current: 130A
- Communication Protocol: Modbus - RS485 & CANBus
- Dimension: 470 x 442 x 180 mm
- Weight: 44kg ± 1kg
-
P/N: L P48280B001
- Nominal Voltage: 51.2V
- Nominal Capacity: 280Ah/14336Wh
- Voltage Range: 40V~58.4V
- Max. Continuous Discharge Current: 100A
- Max. Discharge Peak Current: 130A
- Communication Protocol: Modbus - RS485 & CANBus
- Dimension: 638 x 602 x 232 mm
- Weight: 120kg ± 1kg
